HM3.5 Cubic Self Loading Transit Mixer to Tanzania

Haomei Concrete Pumps2020-03-16

Product Name: HM3.5 Cubic Self Loading Transit Mixer

Destination: Tanzania

Delivery Time: November, 2019

Capacity: 12-14 m3/h

Engine: Yuchai

Function: loading, weighing, pumping, mixing, transport, unloading,washing.

Features: four wheel drive, 270 degree unloading, longer service life

Get quotation: If you like to get the latest self loading transit mixer price, welcome to send inquiry to feedom@haomei-machinery.com

The Specification of Self Loading Mixer

Item

HM3.5 Cubic Self Loading Transit Mixer

LxWxH(mm)

7830x2680x4170

Total Weight

7500kg

Tank Volume

4740L

Concrete Output

3.5m³/batch

Tank Rotation Speed

13-20 rpm

Motor

BM5160

Engine

Yuchai 4105

Engine Power

78kw/106ps

Maximum climbing angle

30°

Speed

30km/h

Minimum ground clearance

380mm

Minimum turning radius

5300mm

Front and rear wheel-base

2900mm

Left and right wheel-base

2100mm

Water tank volume

620L

Fuel tank volume

75L

Fuel consumption(L/h)

12.24L

Feeding time ( minutes/tank)

7 minutes

Original Source: https://www.self-loading-mixer.com/case/hm35-cubic-self-loading-transit-mixer-to-tanzania.html

Tags: self loading transit mixer  |  self loading transit mixer price  |  self loading mixer

Prev: Null

Next: HM2.0 Cubic Self Loading Mixer to Fiji
